Kia Optima Hybrid: Cooling System / Active Air Flap(AAF) Components and Components Location

Kia Optima Hybrid (TF HEV) 2016-2020 Service Manual / Engine Mechanical System / Cooling System / Active Air Flap(AAF) Components and Components Location

Components

1. Air duct
2. Cover
3. Actuator assembly
4. Loader
5. Flaps
6. Link
7. Housing

Active Air Flap(AAF) Description and Operation

Description The AAF (Active Air Flap) is located between radiator grille and radiator, and consists of an actuator and 6 air flaps. The system receives information from EMS, FATC, TCU, MCU and LDC via ...

Active Air Flap(AAF) Schematic Diagrams

Schematic Diagram Circuit Diagram ...
