Kia Optima Hybrid: VESS(Virtual Engine Sound System) / Components and Components Location
| Component Location |
| 1. Virtual engine sound system unit | 2. Virtual engine sound speaker |
Description and Operation
Description The VESS (Virtual engine sound system) generates engine sound when you start the hybrid system. This sound is for pedestrians to hear vehicle sound because there is no engine sound in hybrid ...
